Imaging
Lens Mount
Canon EF-S
Camera Format
APS-C (1.6x Crop Factor)
Pixels
Actual: 25.8 Megapixel
Effective: 24.1 Megapixel
Effective: 24.1 Megapixel
Maximum Resolution
6000 x 4000
Aspect Ratio
1:1, 3:2, 4:3, 16:9
Sensor Type
CMOS
Sensor Size
22.3 x 14.9 mm
Image File Format
JPEG, Raw
Bit Depth
14-Bit
Image Stabilization
Digital, 5-Axis (Video Only)
Exposure Control
ISO Sensitivity
Auto, 100 to 25600 (Extended: 100 to 51200)
Shutter Speed
Mechanical Shutter
1/4000 to 30 Second
Bulb Mode
1/4000 to 30 Second
Bulb Mode
Metering Method
Center-Weighted Average, Evaluative, Partial, Spot
Exposure Modes
Aperture Priority, Manual, Program, Shutter Priority
Exposure Compensation
-5 to +5 EV (1/3, 1/2 EV Steps)
Metering Range
-2 to 20 EV
White Balance
Auto, Cloudy, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten
Continuous Shooting
Mechanical Shutter
Up to 7 fps at 24.1 MP for up to 40 Frames (Raw) / 170 Frames (JPEG)
Up to 3 fps at 24.1 MP for up to 40 Frames (Raw) / 170 Frames (JPEG)
Electronic Shutter
Up to 7.5 fps at 24.1 MP for up to 40 Frames (Raw) / 170 Frames (JPEG)
Up to 7 fps at 24.1 MP for up to 40 Frames (Raw) / 170 Frames (JPEG)
Up to 3 fps at 24.1 MP for up to 40 Frames (Raw) / 170 Frames (JPEG)
Electronic Shutter
Up to 7.5 fps at 24.1 MP for up to 40 Frames (Raw) / 170 Frames (JPEG)
Interval Recording
Yes
Self-Timer
2/10-Second Delay
Video
Recording Modes
MP4/H.264 4:2:0 8-Bit
UHD 4K (3840 x 2160) at 23.976p [120 Mb/s]
Full HD (1920 x 1080) at 23.976p/29.97p/59.94p [12 to 60 Mb/s]
HD (1280 x 720) at 59.94p [26 Mb/s]
UHD 4K (3840 x 2160) at 23.976p [120 Mb/s]
Full HD (1920 x 1080) at 23.976p/29.97p/59.94p [12 to 60 Mb/s]
HD (1280 x 720) at 59.94p [26 Mb/s]
External Recording Modes
UHD 4K (3840 x 2160)
Full HD (1920 x 1080)
HD (1280 x 720)
Full HD (1920 x 1080)
HD (1280 x 720)
Recording Limit
Up to 29 Minutes, 59 Seconds
Audio Recording
Built-In Microphone (Stereo)
External Microphone Input (Stereo)
External Microphone Input (Stereo)
Audio File Format
AAC
Focus
Focus Type
Auto and Manual Focus
Focus Mode
Automatic (A), Continuous-Servo AF (C), Manual Focus (M), Single-Servo AF (S)
Autofocus Points
Phase Detection: 45 (45 Cross-Type)
Autofocus Sensitivity
-3 to +18 EV
Viewfinder and Monitor
Viewfinder Type
Optical (Pentamirror)
Viewfinder Size
Viewfinder Resolution
Viewfinder Eye Point
19 mm
Viewfinder Coverage
95%
Viewfinder Magnification
Approx. 0.82x
Diopter Adjustment
-3 to +1
Monitor Size
3″
Monitor Resolution
1,040,000 Dot
Monitor Type
Articulating Touchscreen LCD
Flash
Built-In Flash
Yes
Dedicated Flash System
eTTL
External Flash Connection
Hot Shoe
Flash Modes
Auto, Manual, Red-Eye Reduction
Maximum Sync Speed
1/200 Second
Flash Compensation
-2 to +2 EV (1/3, 1/2 EV Steps)
Interface
Memory Card Slot
Single Slot: SD/SDHC/SDXC
Connectivity
3.5mm Microphone, USB Micro-B (USB 2.0), HDMI C (Mini)
Wireless
Bluetooth
Wi-Fi
Wi-Fi
Bluetooth
No
Physical
Battery
1 x LP-E17 Rechargeable Lithium-Ion, 7.2 VDC, 1040 mAh (Approx. 1240 Shots)
Weight
1.13 lb / 515 g (Body with Battery and Memory)
