| interface | 4 10/100Mbps RJ45 Ports 1 RJ11 Port |
|---|---|
| Button | 1 Power On/Off Switch 1 WPS Button 1 Wi-Fi On/Off Button |
| External Power Supply | 9VDC/0.85A |
| IEEE Standards | IEEE 802.3, 802.3u |
| ADSL Standards | Full-rate ANSI T1.413 Issue 2, ITU-T G.992.1’G.DMT’, ITU-T G.992.2’G.Lite’ ITU-T G.994.1 ‘G.hs’, ITU-T G.995.1 |
| ADSL2 Standards | ITU-T G.992.3 ‘G.dmt.bis’, ITU-T G.992.4 ‘G.lite.bis’ |
| ADSL2+ Standards | ITU-T G.992.5 |
| Dimensions ‘ W x D x H ‘ | 7.7 * 5.1 * 1.4 in. ‘195 * 130 * 35 mm ‘ |
| Antenna Type | Omni directional, Fixed |
| Antenna Gain | 2x5dBi |
| WIRELESS FEATURES | |
|---|---|
| Wireless Standards | IEEE 802.11n, 802.11g, 802.11b |
| Frequency | 2.400-2.4835GHz |
| Transmit Power | <20dBm’EIRP’ |
| Wireless Security | Support 64/128 bit WEP, WPA-PSK/WPA2-PSK, Wireless MAC Filtering |
| SOFTWARE FEATURES | |
|---|---|
| Quality of Service | QoS Remarking based on IPP/ToS, DSCP and 802.1p |
| Security | NAT Firewall, SPI Firewall, MAC / IP / Packet / Application / URL Filtering, Denial of Service’DoS’, SYN Flooding, Ping of Death |
| Management | Web Based Configuration’HTTP’, Remote management, Telnet management, Command Line Interface, SSL for TR-069, SNMP v1/2c, SNMP over EOC, Web Based Firmware Upgrade, CWMP’TR-069′, Diagnostic Tools |
| Port Forwarding | Virtual Server, DMZ, ACL’Access Control List’ |
| VPN Pass-Through | PPTP, L2TP, IPSec Pass-through |
| ATM/PPP Protocols | ATM Forum UNI3.1/4.0, PPP over ATM ‘RFC 2364’, PPP over Ethernet ‘RFC2516’, IPoA ‘RFC1577/2225’, PVC – Up to 8 PVCs |
| Advanced Features | Traffic Shaping’ATM QoS’ UBR, CBR, VBR-rt, VBR-nrt; Dynamic Host Configuration Protocol ‘DHCP’, DHCP relay; Network Address Translation ‘NAT’; PVC/Ethernet Port Mapping VLAN, 802.1P, Static Routing, RIP v1/v2 ‘optional’; DNS Relay, DDNS, IGMP snooping V1/2 IGMP Multicast, UPnP |
