| Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3x |
|---|---|
| Interface | 24 10/100/1000Mbps RJ45 Ports ‘Auto Negotiation/Auto MDI/MDIX’ |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable ‘maximum 100m’ 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable ‘maximum 100m’ |
| Fan Quantity | Fanless |
| Physical Security Lock | No |
| Power Supply | 100-240VAC, 50/60Hz |
| Power Consumption | Maximum: 13.1W ‘220V/50Hz’ |
| Dimensions ‘ W x D x H ‘ | 11.6*7.1*1.7 in. ‘294*180*44 mm’ |
| Mounting | Rack Mountable |
| Max Power Consumption | 13.62W’220V/50Hz’ |
| Max Heat Dissipation | 46.44BTU/h |
| PERFORMANCE | |
|---|---|
| Switching Capacity | 48Gbps |
| Packet Forwarding Rate | 35.7Mpps |
| MAC Address Table | 8K |
| Jumbo Frame | 10KB |
| Green Technology | Yes |
| Transfer Method | Store-and-Forward |
| OTHERS | |
|---|---|
| Certification | FCC, RoHS |
| Package Contents | 24-Port Gigabit Desktop/Rackmount Switch Power Cord Installation Guide Rackmount Kits Rubber Feet |
| Environment | Operating Temperature: 0℃~40℃ ’32℉~104℉’; Storage Temperature: -40℃~70℃ ‘-40℉~158℉’; Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing |
